3G WIFI Wireless Home Security Alarm system

Set A Package Content
1 x  Central panel
2 x  Remote Control
1 x  Wireless Door/window sensor
1 x  Wireless Infrared Sensor
2 x  RFID card
1 x  Wired Siren
1 x  Power Adapter
1 x  User Manual

Set B Package Content
1 x  Central panel
2 x  Remote Control
3 x  Wireless Door/window sensor
3 x  Wireless Infrared Sensor
2 x  RFID card
1 x  Wired Siren
1 x  Power Adapter
1 x  User Manual

Set C Package Content
1 x  Central panel
3 x  Remote Control
4 x  Wireless Door/window sensor
5 x  Wireless Infrared Sensor
2 x  RFID card
1 x  Wired Siren
1 x  Power Adapter
1 x  User Manual

Set D Package Content
1 x  Central panel
1 x  8292 camera
2 x  Remote Control
1 x  Wireless Door/window sensor
1 x  Wireless Infrared Sensor
2 x  RFID card
1 x  Wired Siren
1 x  Power Adapter
1 x  User Manual

Home WIFI / GSM / 3G / GPRS  alarm

Support APP push, SMS, Voice monitoring, alarm center networking and other alarm ways

to ensure stable and reliable alarm performance

Smart host with new experience

Powerful 32-bit Cortex-M3 core CPU master, 2.4-inch TFT color display

UCOS-Ⅲ operating system, simple style man-machine interface, and menu guide design.

Date clock real-time display, host status at a glance

Chinese / English / German one key switch

Support multi-language menu display, voice operation prompts and alarm SMS settings.

GSM network automatic proofreading, to ensure accurate clock, support time zone settings, convenient for multi-area application

Real-time monitoring alarm

Real-time monitoring of family dynamics, high decibel live alarm through the host timely send SMS notification and APP push when there is an alarm

Super expansion

 5 groups preset alarm phone numbers

SMS on/off and dial on/off can be set respectively

Timely arm/disarm function

1 key arm/disrm, without the trouble of manually

Delay function

User can set arm delay and alarm delay according to own needs

Product Size

Product Details

Specification

• Input Voltage: DC5V/1A(micro USB jack)
• Standby Current: <80uA
• Working Current: <120mA
• Siren output: <500mA
• Wireless Frequency: 433MHZ  EV1527
• GSM Frequency: 850/900/1800/1900MHZ
• Back-up Battery: 3.7V/500mAh Lithium battery
• Working temperature: 0~55  ℃

APP download

Installation diagram

Door sensor installation：double-sided adhesive attached to the door or window,

align the scale line, the installation spacing should less than 1cm

PIR sensor installation: Appropriate installation height is 1.8-2.2M from the ground

Use screws to fix on the wall, adjust mount to appropriate angle
